Hasselblad CFV II 50C - 4.2 Ports and Connections

1
2
3
4
5
6
1 USB port
USB-3typeCforconnectiontoahostcomputeror
iPadPro.
2 Microphone
3.5mmstereoinputforanexternalmicrophone.
3 Headphone
3.5mmstereooutputforheadphones.
4 Flash sync input
Forsynchronizationwithmechanicalshutters.Use
thesuppliedashsyncinputcable.
5 Flash sync output
Forconnectionofexternalashes.Usethesupplied
ashsyncoutputcable.
6 ELX output
ConnectiontoanEL-typecameraortheWinder
CW.EnablesexposureremotecontrolfromPhocus.
See page107forconnectioncables.
