5 System Startup
User Guide 33
This chapter describes how to power up and power down the MLA150. For powering up
and down the system the buttons at the front of the flow box are used.
5.1 Powering Up
Powering up the system:
If not already done, switch on the main switch at the e-rack.
Allow 60 seconds to boot the power supply.
Depending on the system configuration, switch on the User
PC.
To switch on the system power, press the On (I)-button at the
front of the flow box.
You can hear one click and another click 3 seconds later.
In case the system was switched off by using the EMERGENCY OFF button:
Release by turning it in the direction indicated on the button. Otherwise the
system power cannot be switched on.
Press the green On (I)-button.
You can hear one click and another click 3 seconds later.
If power is not coming up, check whether the main
breaker on the bottom of the electronics rack is turned
off. Turn on the main breaker again!
Switch on the displays and the User PC, if it is not running.
In case the power supply was interrupted (e.g. by a blackout)
Press the green On (I)- button.
You can hear one click and another click 3 seconds later
Reboot the User PC.
Starting the Exposure Wizard:
Click the shortcut at your desktop.
