96
_____________________________________________________________________________________________
7.4 Command Reference
______________________________________________________________________________________________
Syntax
:CONFigure:VOLTage[:DC][ data]
:CONFigure:VOLTage:AC[ data]
:CONFigure:CURRent:DC[ data]
:CONFigure:CURRent:AC[ data]
:CONFigure:RESistance[ data]
:CONFigure:LPResistance[ data]
:CONFigure:FRESistance[ data]
:CONFigure:LPFResistance[ data]
:CONFigure:CLAMp:DC data
:CONFigure:CLAMp:AC data
:CONFigure:FREQuency data
:CONFigure:DIODe
data
NRf numerical data
An expected measurement value is entered. The unit is set to an optimum range capable of
measuring the given numerical data. (In the case of a frequency measurement function, the
attenuator range is specified.) [ data] can be omitted. If this input is omitted, Auto Range will be
set up.
Function
The CONFigure command functions as follows:
Places the trigger system in a one-shot trigger mode. (Except when measuring continuity.)
Selects the internal trigger source.
Shifts to the specified function.
Shifts to the specified range.
Specifically, the CONFigure command executes the following command internally:
:FUNC <Function>
<Function>:RANG <data>
In the absence of (<data1>):<Function>:RANG:AUTO 1
:INIT:CONT 0
:TRIG:SOUR IMM
Example
/∗ Initial setting ∗/
Transmission CONF:VOLT:AC 5.3
Sets up the AC voltage function and 20 V range and places the trigger system in
a one-shot trigger mode.
/∗ Measurement ∗/
Transmission READ?
Performs a single measurement.
Response 3.289500E+00
The measurement value is 3.2895 V.
:CONFi
g
ure command
Presetting of Ranges and Functions
