Hioki 3237 - Page 150

138
_____________________________________________________________________________________________
10.2 Accuracy
______________________________________________________________________________________________
Range
Maximum
display
Input
resistance
Overload protection
100 Hz 99.9999 Hz
1MΩ 10 ％
DC600 V, AC750 Vrms
1000 Vpk (10
7
V Hz or less,
continuous)
1 kHz 999.999 Hz
10 kHz 9.99999 kHz
100 kHz 99.9999 kHz
300 kHz 999.999 kHz
Continuity Test Function
(1) Range
Range: 2000 Ω
Maximum display: 1999.99 Ω
Measurement current: 100 uA
5%
Open-circuit voltage: 0.45 Vmax.
Overload protection: 500 Vpk
(2) Threshold
The buzzer beeps when (Measurement Value) < 50.00 Ω.
Diode Test Function
(1) Range
Range: 2000 mV
Maximum display: 1999.99 mV
Measurement current: 1 mA
5%
Overload protection: 500 Vpk
(2) Accuracy
Range: 2000 mV
SLOW: 100 ppm rdg. 2 dgt.
MEDIUM: 100 ppm rdg. 8 dgt.
FAST: 150 ppm rdg. 100 dgt.
Temperature coefficient: 10 ppm rdg./ 0.2 dgt./
Frequency Function
(1) Range
(2) Accuracy (10 Hz to 300 kHz, 10 Vpp, square wave)
150 ppm rdg. 2 dgt.
Temperature coefficient: 5 ppm rdg./
(3) Attenuator
2 V, 20 V, 200 V, 700 V
(4) Input sensitivity
10% of attenuator range
Sampling Period (Free run)
