Hioki 3237 - Page 151

139
_____________________________________________________________________________________________
10.2 Accuracy
______________________________________________________________________________________________
Power supply
frequency
SLOW MEDIUM FAST
*
50 Hz 1.04 0.05[sec] 130 5[msec] 3.33 1[msec]
60 Hz 1.08 0.05[sec] 108 5[msec] 3.33 1[msec]
Power supply
frequency
SLOW MEDIUM FAST
*
50 Hz 1.04 0.05[sec] 130 5[msec] 20 1[msec]
60 Hz 1.08 0.05[sec] 108 5[msec] 16.7 1[msec]
Power supply
frequency
SLOW MEDIUM FAST
*
50 Hz 1.36 0.05[sec] 170 5[msec] 20 1[msec]
60 Hz 1.42 0.05[sec] 142 5[msec] 16.7 1[msec]
SLOW MEDIUM FAST
*
1.01 0.02[sec] 110 10[msec] 15 6[msec]
SLOW MEDIUM FAST
DCV 130 dB 90 dB 20 dB
ACV 60 dB 60 dB 30 dB
SLOW MEDIUM FAST
DCV 70 dB 50 dB 0dB
(1) DC voltage measurement, AC voltage measurement, DC current, AC
current measurement, Clamp scaling, Resistance measurement (200
Ω to 2 00 kΩ range), Low-power resistance measurement (2/20 kΩ
range), Continuity test, Diode test
*: With the FAST sampling period set, the unit performs a calibration every
30 minutes for a period of 65
10 ms.
(2) Resistance (2 MΩ range), Low-power resistance (200 kΩ/2 MΩ range)
*: With the FAST sampling period set, the unit performs a calibration every
30 minutes for a period of 65 10 ms.
(3) Resistance (20 to 100 MΩ range)
*: With the FAST sampling period set, the unit performs a calibration every
30 minutes for a period of 65 10 ms.
(4) Frequency measurement gate time
Measurement time: Twice the gate time-input signal period.
CMRR, NMRR
(1) CMRR
With respect to 50/60 Hz
1%,For1kΩ unbalance in COM terminal
(2) NMRR (DC Voltage function)
50/60 Hz 1%
