61
_____________________________________________________________________________________________
7.2 Communication
______________________________________________________________________________________________
Bit 7
Not used
Bit 6
Not used
Bit 5
-OF
Minus over load
Bit 4
+OF
Plus over load
Bit 3
HI
Comparator result: Hi
Bit 2
IN
Comparator result: IN
Bit 1
LO
Comparator result: Lo
Bit 0
EOC
Measurement completed.
Register Read Write
Status byte register
∗STB?
Service request enable register
∗SRE? ∗SRE
Standard event status register
∗ESR?
Standard event status enable register
∗ESE? ∗ESE
Event status register 0 :ESR0?
Event status enable register 0 :ESE0? :ESE0
(2) Event status enable register 0
These event status enable registers mask the corresponding event status
registers.
Summary of commands for writing and reading each of the registers
