49
3.6 Battery Measurement
索引
4
3
2
1
7
6
5
10
9
8
Measurement
<Ex.>
As shown above, this battery needs to be replaced.
4.
Hold the measurement values by pressing key or
the PRESS button on the remote control switch.
5.
Use the measurement values to judge battery wear.
OR
Measurement
value
FAIL
WARNING
PASS
Current
value
(1.864 V)
Initial value
(2.008 V)
Voltage
Initial value
(0.428 mΩ)
Current value
(0.722 mΩ)
Resistanc
e
Wear
