3.6 Battery Measurement
Remove the test lead from the battery and turn off
the power to the instrument by pressing but-
ton.
Stabilizing
measurement values
(⇒ p.73)
Storing measurement
values
Measurement values can be
stored by pressing key
while the values are being
held.(⇒ p.44)
Loading stored data to
a personal computer
(⇒ p.103)
Configuring threshold
values and judging bat-
tery wear
Based on these wear judg-
ment values, threshold values
can be configured for judging
battery wear.(⇒ p.13)
• A measurement value display of "OF" indicates
that the resistance or voltage values displayed
exceed the relevant measurement range.
• If the voltage input is "OF," a buzzer will sound.
• A resistance value display of "- - - -" indicates
that the test lead is open or measurement cannot
be conducted due to an electrical current irregu-
larity caused by a disconnected test lead or other
reasons. "- - - -" will also be displayed when the
test lead is not correctly connected to the subject
of measurement or the subject's resistance is
substantially greater than the measurement
range.
• When measuring resistance of a relay or a con-
nector, note the maximum open circuit voltage of
this instrument (approximately 5 V). There is a
possibility that such measurement could damage
the connectors or oxidized coating of the subject
of measurement, leading to incorrect measure-
ment.
Ending the Measurement
To Next Page
