4.3 Setting Comparator Permissible Values
Setting Voltage Lower Limit
1.
Press / keys to set
the values of voltage lower
limit.
Press / keys to select
digits.
2.
Press key to save the
settings.
This will return the display to
the measurement screen,
with the comparator feature
on.
At this point, configuration
settings are saved.
In this example, 1.800 V has
been selected
Voltage values are judged using absolute values.
For this reason, judgment can be made even when
the polarity of the test lead is reversed. (Data is
also saved using absolute values.)
