User Interface
10.3 User Interface
Display
Monochrome graphic LCD 240 × 110
Screen size 94 W × 55 H mm (View area)
Backlight White LED
Brightness adjustment range: 10% to 100% (in 5% steps)
Contrast Adjustment range: 0% to 100% (in 5% steps)
10.4 External Interface
Communication Interface
Interface types RS-232C/USB
(Both RS-232C and USB cannot be controlled simultaneously. When both the USB and
the RS-232C communication are connected, the USB connection is effective.)
RS-232C
Communication
contents
Remote control, measured value output
Transmission method Start-stop synchronization system, full duplex
Transmission speed 9,600 bps/19,200 bps/38,400 bps
Data bit length 8 bit
Stop bit 1
Parity bit None
Terminator Sending: CR+LF
Receiving: CR, CR+LF
Delimiter Sending: CR+LF
Receiving: CR, CR+LF
Handshake X ow: Not provided, Hardware ow: Not provided
Protocol Non-procedure system
Connector D-sub9 pin, male, mating xed base screw #4-40
USB
Communication
contents
Remote control, measured value output
Electrical
specications
USB2.0 (pseudo COM port)
Class CDC class
Connector Series B receptacle
