Basic Measurement Examples
3.7 Basic Measurement Examples
In this section, setting the battery cell is explained as an example.
Examples of setting contents
Measurement functions R, X, V, T
Measurement Range 100 m
Ω
Measurement
speed
Impedance
measurement
FAST
Voltage measurement SLOW
Impedance measurement frequency 1 Hz
Zero adjustment ALL
1
Set the measurement functions (R, X, V, T). (p. 21)
2
Set the measurement range at 100 m
Ω
. (p. 22)
3
Set the measurement speed of impedance measurement (Z) at [FAST]. (p. 23)
3
Basic Measurement
