Hioki BT4560 - Adjusting the Backlight

67
Adjusting the Backlight
7.4 Adjusting the Backlight
The brightness of the backlight can be adjusted for the illumination of the installation location.
When the trigger source is set from the external trigger, if the status with no operation continues
for 1 minute, the brightness of the backlight will become dim automatically.
1
Press (MENU). (The setting screen appears.)
2
Select [SYST] tab.
Selection
3
Adjust the backlight.
: Raise the backlight brightness.
: Drop the backlight brightness.
Setting range : 10% to 100%, steps of 5% (default setting: 80%)
Conrm
(or)
Cancel
Setting
Move to the next digit
(left or right)
Changing the numerical
value (up and down)
7
System Setting
