Redundancy
158
8.3 Redundant coupling
RM Web L3P
Release 4.1 03/08
Note: Configure the coupling port and the HIPER-Ring ports on different
ports.
 Activate the function in the “Operation” frame (see fig. 59).
 You now connect the redundant line and the control line.
The displays in the “Select port” frame mean (see fig. 59):
– “Port mode”: The port is either active or in stand-by mode.
– “Port state”: The port is either connected or not connected.
– “IP Address”: The IP address of the partner, if the partner is already
operating in the network.
The displays in the “Information” frame mean (see fig. 59):
– “Redundancy guaranteed”: One of the lines affected can fail, as a
redundant line will then take over the function of the failed line.
– “Configuration failure”: The function is incomplete or incorrectly
configured.
Switch Coupling port Control port
RS2-../.. Port 1 Stand-by port (can only be combined
with RS2-../.. )
RS2-16M Adjustable for all ports
(default setting: port 1)
Adjustable for all ports
(default setting: port 2)
RS20 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
RS30 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
RS40 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
MICE Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
PowerMICE Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
MS 20 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
MS 30 Adjustable for all ports
(default setting: port 2.4)
Adjustable for all ports
(default setting: port 2.3)
RSR20/RSR30 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
MACH 1000 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
MACH 3000 Adjustable for all ports Adjustable for all ports
MACH 4000 Adjustable for all ports
(default setting: port 1.4)
Adjustable for all ports
(default setting: port 1.3)
Table 32: Port assignment for the redundant coupling
