Redundancy
RM Web L3P
Release
4.1
03/08
8.2
HIPER-Ring
133
8.2.1 Configuring HIPER-Ring Version 1
Set up the network to meet your requirements.
Note: Before you connect the redundant line, you must complete the
configuration of HIPER-Ring Version 1.
You thus avoid loops during the configuration phase.
Note: Configure each HIPER-Ring device.
Select the Redundancy:HIPER-Ring dialog.
Select Version 1.
Note: As an alternative to using software to configure HIPER-Ring Version 1,
with devices RS20/30/40, MS20/30 and PowerMICE you can also use a DIP
switch to enter a number of settings for HIPER-Ring Version 1. You can also
use this DIP switch to enter a setting for whether the configuration via DIP
switch or the configuration via software has priority. The state on delivery is
“Software Configuration”.
For each device, you enter the desired ring ports 1 and 2.
The following settings are required for the ring ports (select the Basic
Settings:Port Configuration dialog):
Bit rate 100 Mbit/s 1000 Mbit/s
Autonegotiation
(automatic configuration)
Off On
Port On On
Duplex Full –
Table 25: Port settings for ring ports
