Redundancy
142
8.3
Redundant coupling
RM Web L3P
Release
4.1
03/08
8.3 Redundant coupling
8.3.1 Configuring the redundant coupling
STAND-BY switch
The Switches have a STAND-BY switch for selecting between the main
coupling and the redundant coupling. Depending on the Switch, this
switch is a DIP switch or a software switch (Redundancy:Ring/Net-
work Coupling dialog), or you can use a switch to select one of the two
options.
Depending on the Switch used, you choose between the main coupling
and the redundant coupling (see table 28).
Switch STAND-BY switch
RS2-../.. DIP switch
RS2-16M DIP switch
RS20/RS30/RS40 Can be switched between DIP switch and software switch
MICE/PowerMICE Can be switched between DIP switch and software switch
MS 20/MS 30 Can be switched between DIP switch and software switch
RSR20/RSR30 Software switch
MACH 1000 Software switch
MACH 3000/MACH 4000 Software switch
Table 27: STAND-BY switches of the Switches
