Diagnostics
198
9.7
Alarms (Traps)
RM Web L3P
Release
4.1
03/08
9.7 Alarms (Traps)
This dialog allows you to determine which events trigger an alarm (trap) and
where these alarms should be sent.
Select "Create entry".
In the "Address" column, enter the IP address of the management station
to which the traps should be sent.
In the "Enabled" column, you mark the entries which should be taken into
account when traps are being sent.
In the "Selection" frame, select the trap categories from which you want
to send traps.
Note: You need read-write access for this dialog.
The events which can be selected are:
Name Meaning
Authentication The device has rejected unauthorized access attempt, see dialog„SNMPv1/
v2 Access Setting“ on page 42 and „Port Mirroring“ on page 191.
Link Up/Down At one port of the device, the link to a device connected there has been
established/interrupted.
Spanning Tree The topology of the Rapid Spanning Tree has changed.
Chassis Encompasses the following events:
– The status of a supply voltage has changed (see the System dialog).
– The status of the signal contact has changed.
To take this event into account, you activate “Create trap when status
changes” in the Diagnostics:Signal Contact 1/2 dialog.
– A media module has been added or removed.
- The auto configuration adapter (ACA) has been added or removed.
- The temperature threshold has been exceeded/not reached.
Redundancy The redundancy status of the Hiper-Ring or the redundant ring/network
coupling has changed.
Port security On one port a data packet has been received from an unauthorized terminal
device (see the Port Security dialog).
Table 43: Trap categories
