Basic Settings
20
2.1 System
RM Web L3P
Release 4.1 03/08
Figure 6: Availability of the media modules
 Device view
The device view shows the device with the current configuration. The
symbols underneath the device view represent the status of the individual
ports.
Figure 7:
Module present
Empty slot
Module was removed.
Click this check mark
to define this slot as an
empty slot.
