Holden WM Caprice Owner Manual (MY12.5) - 2012 - CRC 1st Edition - 6/28
/
12
Vehicle Care 10-33
Engine compartment fuse and
relay index
The vehicle may not be equipped
with all of the fuses, relays and
features shown.
FU1 BRAKE
VACUUM PUMP
(20A)
FU2 REAR DEFOG (40A)
FU3 ABS MOTOR (40A)
FU4 SPARE
FU5 BATT MAIN 1 (50A)
FU6 SPARE
FU7 BATT MAIN 2 (50A)
FU8 STARTER (40A)
FU9 HVAC BLOWER
MOTOR
(40A)
FU10 FAN 1 ENGINE
COOLING
(30A)
FU11 SPARE
FU12 FAN 2 ENGINE
COOLING
(30A)
F1 COMM ENABLE (10A)
F2 HVAC BATT (10A)
F3 REVERSE LIGHT (10A)
F4 FOG LIGHTS
(FRONT)
(15A)
F5 ABS VALVES (25A)
F6 SPARE
F7 HEADLIGHT
WASH
(30A)
F8 HORN (15A)
F9 TCM (15A)
F10 LEFT LOW BEAM
(BASE/HID)
(10/
20A)
F11 VAPORISER
CONTROL
MODULE (VCM)
(10A)
F12 RIGHT LOW
BEAM (BASE/HID)
(10/
20A)
F13 SPARE
F14 SPARE
F15 FR ONT WIPER (30A)
F16 SPARE
F17 THEFT HORN (10A)
F18 A/C CLUTCH (10A)
F19 RIGHT
HIGH BEAM
(10A)
F20 SPARE
F21 FRONT
WASHER (WSW)
(15A)
F22 SPARE
F23 LEFT HI BEAM (10A)
F24 SPARE
F25 REVERSE
LOCKOUT/TOSS/
FLEX FUEL SNSR
(15A)
F26 REAL TIME
DAMPING
(25A)
F27 SPARE
F28 ECM 1-V8/ODD
COILS-V6
(15A)
F29 EVEN COILS-V6/
EVEN INJECTORS
& COILS-V8
(20A)
F30 SPARE
F31 SPARE
