Honeywell 301C User Manual

62 301C User Manual 510324
Honeywell 4/07
System Programming
Config Menu
Scroll through the main Config menu screens using the left (previous)
or right (next) keypad arrows.
The third main screen in the Config menu allows you to set the relay
configuration, the AP broadcast mode and to select from four separate
manufacturers for the given controller.
When you select Relay Configuration, you have two further options to
configure the relays: The first screen, Failsafe, appears allowing you to
activate the failsafe for all relays using the Enter keypad button. This
function is used in case of a power failure: if power is cut, the relay will
activate the connected device (ex. a light) to signal the problem.
Scrolling to the right displays the “Silence” screen that lets you enable
or disable the silence option for each relay, using the Enter keypad
button.
6. Config
Relay Configuration
AP Brdcst: auto
Honeywell
Relay Configuration
-Failsafe-
All relays
Inactive
Relay Configuration
-Silence-
1234
dis ena dis dis

Honeywell 301C Specifications

General

Controller Type	Temperature Controller
Control Mode	ON/OFF, PID
Input Voltage	100-240 VAC
Input	Thermocouple, RTD
Output	Relay, SSR
Operating Temperature	0 to 50°C
Contact Rating	5A @ 250 VAC (Relay)
