System Programming
Config Menu
The second main screen in the Config menu allows you to set a new
user password and to modify the slave port configuration.
The default password is 2967. Select Set User Password to change
your password:
• When the first digit blinks, change the value by using the up/down
keypad arrows to increase or decrease the number
• Use the left/right keypad arrows to move from one digit to the next.
• When you have the desired password, press Enter to validate it and
exit the editing mode.
Note: Contact Honeywell technical support for help with lost passwords
at 1-800-563-2967.
To change the address, baud rate or to view the communication
protocol for the slave port:
Place the cursor arrow next to Slave Port Cnfg and press Enter.
• Use the keypad arrows to scroll to the desired parameter (address
or baud rate)
• Press Enter to select the parameter
• Use the arrows to scroll through the list of available settings
• Press Enter to validate the new parameter and exit the field.
6. Config
Set User Password
- 2967 -
Slave Port Cnfg
Slave Port Cnfg
Address: 001
38400 bauds
Mdbs RTU 8D 2S NP
