Honeywell C300 - Hardware Information Tab

5. C300 Configuration Form Reference
5.1. C300 Controller Block
10
0
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
Hardware Information tab
The Hardware Information tab contains data describing the C300 Controller module
device including firmware and hardware revision and version information. The
parameters provided here are used for maintenance, troubleshooting and problem
description purposes. The following table summarizes the parameter data you can view
on the Hardware Information tab of the configuration form for the selected C300
block.
Plain Text
Parameter Name
User
Configurable
Notes
Firmware Version
Boot Image Version
BOOTIMAGEVER
No
Shows the current version
of boot firmware installed
in the module.
Application Image
Version
See Note 1
IMAGEVER_D
No
Shows the current version
of application firmware
installed in the module.
Hardware Factory Information
Module Type
MODTYPE
No
Identifies the model
number and identification
string of the module.
Serial Number
SERIALNUM
No
Identifies the serial
number of the module.
Programmable Logic
Version
PLREVISION
No
Identifies the version of
the programmable logic
set of the module.
Hardware Version
HWREVMAJ
No
Identifies the major
hardware revision number
of the module.
Hardware Revision
HWREVMIN
No
Identifies the minor
hardware revision number
of the module.
Network Interface Address Information
FTE Interface A MAC
Address
MACADDRA
No
Identifies Ethernet MAC
Address of FTE Interface
A (Yellow Tree Port)
