Honeywell C300 - Load C300 Controller Configuration

5. C300 Configuration Form Reference
5.4. IOLINK Block
R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
153
Plain Text
Parameter Name
User
Configurable
Notes
Channel B- Edges
SECCHNMNB
No
Shows the number of
I/O link channel B
missed minus edge
transitions encountered
by the Secondary
IOP/IOM.
Channel B+ Edges
SECCHNPLB
No
Shows the number of
I/O link channel B
missed plus edge
transitions encountered
by the Secondary
IOP/IOM.
Last Error
SECCOMMERR
No
Indicates the last I/O
Link communication
error experienced by
the Secondary IOP.
I/O Status Summary tab
The Status Summary tab contains additional statistics for Series 8 IOMs residing on the
IOLINK, which is used for maintenance and performance monitoring of the IOLINK
interface. The following table summarizes the parameter data you can monitor and/or
configure on the Status Summary tab of the configuration form for the selected IOLINK
block.
Plain Text
Parameter Name
User
Configurable
Notes
IOP/IOM Number
IOP Block Name
IOPBLOCKNAME
No
Indicates the
corresponding Primary
IOP/IOM Tag.
Configured IOP Type
IOMTYPE
No
Indicates the configured
IOP type.
IOP Status
IOMSTSA and
IOMSTSB
No
Shows the status of the
specific physical I/O
Module.
