5. C300 Configuration Form Reference
5.1. C300 Controller Block
106
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
Plain Text
Parameter Name
User
Configurable
Notes
Current Connections
TCPCURRESTAB
No
Number of TCP
connections for which
current state is either
ESTABLISHED or
CLOSE-WAIT.
Segments Received
TCPINSEGS
No
Total number of segments
received, including those
received in error.
Segments Sent
TCPOUTSEGS
No
Total number of segments
sent, including those on
current connections but
excluding those containing
only retransmitted octets.
Segments
Retransmitted
TCPRETRANSSEGS
No
Total number of segments
retransmitted - that is,
number of TCP segments
transmitted containing one
or more previously
transmitted octets.
Segments Discarded
for Errors
TCPINERRS
No
Total number of segments
received in error (for
example, bad TCP
checksums).
Reset Segments
Sent
TCPOUTRESETS
No
Number of TCP segments
sent containing the RST
flag.
IP/ICMP tab
The IP/ICMP tab displays statistics related to IP and ICMP protocol messages associated
with (that is, originating in or received by) this C300 Controller. These types of messages
are generally associated with maintenance and status operations on the network. The
following table summarizes the parameter data you can monitor on the IP/ICMP tab of
the configuration form for the selected C300 block.
Plain Text
Parameter Name
User
Configurable
Notes
