4.2
Create C300 Controller and CEE function blocks
You can create function blocks that represent a C300 Controller and its associated
Control Execution Environment (CEE). Once created, the function blocks appear in the
Project tab view of Control Builder. The CEEC300 block supports execution of a set of
function blocks for solving control applications which run in the C300 as a software layer
built on top of the control software infrastructure.
Two additional EE blocks are also created when a C300 Controller block is created.
These blocks, IOLINK1 and IOLINK 2, provide the controller interface for associated
Series 8 Module blocks.
Prerequisites
You have started Configuration Studio and launched the Control Builder application.
You have logged on with sufficient privileges to create control strategies using
Control Builder.
You have configured the applicable IP addresses when you set up your FTE network.
You have configured applicable Base IP address and IP addresses for Network Time
Protocol (NTP) Servers through the System Preferences dialog in Control Builder.
Refer to the Setting system preferences in the Control Building User's Guide for more
information about setting IP addresses.
TIP
You can configure a C300 Controller block in the Control Builder Project tab
without the controller hardware being installed.
