Honeywell C300 User Manual

4. C300 Controller Configuration
4.11. Assign Control Modules and IOMs to a CEEC300 block
72
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
Step
Action
5
Click OK.
Configuration form closes.
6
If necessary, double-click on the newly-named Control Module in the Project
Tree to open it. The new name appears at the top of the Control Module
drawing when the control drawing opens.
7
Click File > Save to save any additional changes you make to the Control
Module before closing.
8
Click File > Close to close the chart.
4.11 Assign Control Modules and IOMs to a CEEC300
block
Once a Control Module (CM) or Sequential Control Module (SCM) is created, you can
assign it to a CEEC300 block of a C300 Controller. Use the following procedure as a
general guide to assign configured CMs and I/O Modules (IOMs) to the CEEC300 block.
Note that in the C300 controller environment can be assigned only to the CEEC300
block.
Prerequisites
 Control Builder is running
 Tree windows are open
Considerations
All illustrations used in the procedure are for example purposes only.
For additional information on CM assignment, refer to the Control Building Users Guide;
or for SCM assignment, the Sequential Control User's Guide.

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
