Honeywell C300 - Control Confirmation Tab; Identification Tab

5. C300 Configuration Form Reference
5.1. C300 Controller Block
116
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
Plain Text
Parameter Name
User
Configurable
Notes
Pos #
GROUP.POSITION
Yes
Defines number of position
configured parameter will
occupy in the Station Group
display.
Group Parameter
GROUP.PARAM
Yes
Valid parameter name for a
parameter associated with
the given point that is
configured in the system.
Description
No
Provides a brief description
of the entered parameter.
Control Confirmation tab
The Control Confirmation tab is common to all configuration forms for tagged blocks
in Control Builder. Refer to the online help and the Station Configuration Guide for
information about the data on this tab.
Identification tab
The Identification tab is common to all configuration forms for tagged blocks in Control
Builder. The following table summarizes the parameter data you can monitor and
configure on this tab of the configuration form for the selected C300 block.
Plain Text
Parameter Name
User
Configurable
Notes
Name
Name
Yes
Unique block name
consisting of up to 16
characters to identify the
block. At least one
character in the name must
be a letter (A-Z).
Description
DESC
Yes
Descriptive text that
appears on detail and
group displays to uniquely
describe this particular
function block.
Block Comment 1
BLCKCOMMENT1
Yes
Comment to be associated
with this block consisting of
up to 40 characters.
