5. C300 Configuration Form Reference
5.1. C300 Controller Block
R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
111
Plain Text
Parameter Name
User
Configurable
Notes
Battery State
Warning
BATTERYNOTOKSFTA
B
No
Indicates the status of the
battery. Status is also
shown on Main tab of
C300 block.
The Battery State Warning
soft failure condition is
indicated when the C300
does not have a battery
backup and the “Disable
Battery Alarm and Soft
Fail” field in the Main tab is
not checked.
Device Index
Switches Changed
BCDSWSTS
No
Online diagnostic warning:
Switches broken or
deliberately changed.
Factory Data Error
FACTDATAERR
No
Online diagnostic error
reading factory data.
ROM Application
Image Checksum
Failure
ROMAPPIMGCHKSMF
AIL
No
Online diagnostic error:
ROM application image
may be corrupted.
ROM Boot Image
Checksum Failure
ROMBOOTIMGCHKSM
FAIL
No
Online diagnostic error:
ROM boot image may be
corrupted.
WDT Hardware Error
WDTHWFAIL
No
Online diagnostic error:
Fault detected in the
Watchdog Timer hardware
circuit.
WDT Refresh
Warning
WDTSWFAIL
No
Online diagnostic warning:
Watchdog Timer is being
refreshed late and close to
the timeout limit.
Critical Task
Watchdog Warning
TASKHLTHMON
No
A key task within the
controller is executing less
frequently than normal.

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
