7. C300 Controller Operation
7.2. C300 faceplate indicators/displays
Series 8 C300 Controller User's Guide
Honeywell
C300 State
(PCMSTATE)
shown on
Station and
Control Builder
displays
source, or time server is not available - Transient state, No
CDA.
Controller not able to communicate with other nodes.
Factory Test mode - Non product state, No CDA.
Failure in Module - No CDA.
Boot mode with no valid application image - No CDA
Boot mode with application image - No CDA
Firmware load in progress - No CDA
Firmware flash in progress - No CDA
Application mode with no database - CDA present
Application node with no CEE, but C300 FB present with
CDA. This is a transient state during loading C300 FB or
when deleting CEE FB/C300 FB
Application mode with database loaded, all EEs good with
controller in IDLE - CDA present
Application mode with database loaded, all EEs good with
controller in RUN - CDA present
Application mode with database loaded, all EEs good,
module is secondary - CDA present
One or more soft fail conditions are present in the C300
Controller. This state is independent of either CEE state
or Redundancy role.
Note 1: (####) - This symbol does not appear on the C300 Controller faceplate display. It appears
on Control Builder and operator (Station) displays representing the C300 Controller to indicate
that the C300 Controller is OFFNET and this data is not available at this time. Controller will
continue to display the existing or changing faceplate display indication per the current controller
state. As a result of communication failure, CDA will return OFFNET as C300 Module State.
