Honeywell C300 User Manual

188
Series 8 C300 Controller User's Guide
Honeywell
R500
April 2017
7. C300 Controller Operation
7.4. Control Builder block icon descriptions
Icon
Represents . . .
C300 Controller
(C300STATE)
(red)
C300 is non-redundant and not communicating.
No Communication
(Offnet)
(red, simulation)
C300 is non-redundant. Simulation mode
enabled.
No Communication
(Offnet)
(red & white)
Primary C300 is not communicating.
No Communication
(Offnet)
(white & red)
Secondary C300 is not communicating.
No Communication
(Offnet)
(yellow)
C300 is non-redundant.
No Database
(yellow,
simulation)
C300 is non-redundant. Simulation mode
enabled.
No Database
(yellow & yellow)
Primary C300 is not synchronized and partner
C300 is visible
No Database
(yellow &
shadow)
Primary C300 is not synchronized and partner
C300 is absent or incompatible
No Database
(blue)
C300 is non-redundant.
Idle
(blue,
simulation)
C300 is non-redundant. Simulation mode
enabled.
Idle
(blue & white)
Primary C300 is synchronized.
Idle
(blue & white,
pause)
Primary C300, standby synchronization.
Idle
(blue & yellow)
Primary C300 is not synchronized and partner
C300 is visible.
Idle
(blue & shadow)
Primary C300 is not synchronized and partner
C300 is absent or incompatible.
Idle
(green)
C300 is non-redundant.
Run or OK

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
