7. C300 Controller Operation
7.4. Control Builder block icon descriptions
Icon
Represents . . .
C300 Controller
(C300STATE)
(blue & shadow)
Primary C300 is not synchronized and partner
C300 is absent or incompatible.
Idle Soft Fail
(green)
C300 is non-redundant.
Run Soft Fail or OK
Soft Fail
(green,
simulation)
C300 is non-redundant. Simulation mode
enabled.
Run Soft Fail or OK
Soft Fail
(green & white)
Primary C300 is synchronized.
Run Soft Fail or OK
Soft Fail
(green & white,
pause)
Primary C300, standby synchronization.
Run Soft Fail or OK
Soft Fail
(green & yellow)
Primary C300 is not synchronized and partner
C300 is visible.
Run Soft Fail or OK
Soft Fail
(green &
shadow)
Primary C300 is not synchronized and partner
C300 is absent or incompatible.
Run Soft Fail or OK
Soft Fail
(white & green)
Secondary C300 is synchronized.
Backup Soft Fail
(white & green,
pause)
Secondary C300, standby synchronization.
Backup Soft Fail
(yellow & yellow)
Secondary C300 is not synchronized and
partner C300 is visible partner present.
Backup Soft Fail
(shadow &
yellow)
Secondary C300 is not synchronized and
partner C300 is absent or incompatible
Backup Soft Fail

Honeywell C300 Specifications

General

Memory	512 MB RAM, 512 MB Flash
Type	Process Controller
Communication Ports	Ethernet, Serial
Power Supply	24V DC
Inputs	Analog and Digital
Outputs	Analog and Digital
Communication	Ethernet, Serial, HART
Redundancy	Supported (Hot Standby)
