Honeywell C300 - Page 83

R500
April 2017
Series 8 C300 Controller User's Guide
Honeywell
79
4. C300 Controller Configuration
4.13. Assign I/O Modules to C300 IOLINK blocks
Step
Action
Result
3
Change the Control Module block's
Tagname in the Destination column of
the Name New Function Block(s) dialog
to a desired name or accept the default
name.
The copied Control Module block is
assigned a new name.
Note: You may choose to keep the
default name which is simply the
original name with a number
appended to it.
4
Click Next to proceed to the next dialog
page (if appropriate) and enter new
names as prompted to resolve any
existing connections and/or
associations.
If the CM contains connections to
outside blocks, an additional dialog
page appears which is used to
resolve any existing connections
and/or associations.
5
Click Finish.
Copied Control Module block with
newly-designated name is pasted
onto the Project Tree.
