4. C300 Controller Configuration
4.14. Add an I/O Channel to a Control Module
To add IO Channel blocks to a Control Module chart, perform the following steps.
Step
Action
Result
1
Make sure a Control Module (CM) chart
is open.
Double-click the CM in the Project Tree
to open your CM chart so function blocks
may be added.
See Creating and Saving a Control
Module.
The Control Module (CM) chart is open
so that function blocks may be added.
2
From the appropriate Library Tree group,
drag and drop the desired block (or
blocks) to the Control Module Control
Drawing (such as an AICHANNEL block
from the Series 8 group).
Desired block is shown in reverse video
on the tree.
The new function block appears on the
Control Module chart.
TIP
You can drag and drop Series 8 Input/Output Channel (IOC) blocks directly from IO
Ms added to the Project tab to the Control Module.
You cannot add IOC blocks to Control Modules already assigned to a Fieldbus
Interface Module (FIM).
3
Repeat Step 2 as many times as necessary to create the desired blocks for your
control strategy.
4
Create your control strategy by connecting the function blocks using the Insert wire
option.
REFERENCE - INTERNAL
For details to connect function blocks, see Connecting and disconnecting
blocks in the Control Building Guide.
If you are building a control strategy to include insertion points, refer to
Creating a strategy to use insertion points in the Control Building User’s
Guide.
