GX-Series Control Panel Installation and Setup Guide
6-78
The following fault types will activate the fault output:
Line fail (any module), ARC comms fail (any module), RF jam, RF low battery, RF supervision failure, Bell
fail (from a bell fail zone), AC fail (panel, AC zone or power supply), Battery fail (panel, battery zone or
power supply), Mask.
SMS signaling faults will not activate the fault outputs.
77 Bell Test
This output activates when Bell Test is selected via menu 32. This causes the bell and strobe output to
activate. This output is normally used to activate a relay to cut power to the bell.
78 Comms Test (Pulse)
This output is used for remote routine inspection, via the downloader software. When a remote inspection is
carried out, this output will activate for 10 seconds in order to trigger the test input of an external comms
device.
79 Door Prop
This output activates when a door is held open for longer than the programmed time and an Open Timeout
occurs (Option 69).
80 Door Force
This output activates when a door is forced open without authorization and an alarm occurs.
81 Listen-in
This output activates after an alarm activation and an audio transmission is in progress.
