GX-Series Control Panel Installation and Setup Guide
1-1
INTRODUCTION
This manual gives full instructions required to install and program a GX-Series control panel and associated
peripherals.
The GX-Series provides the following features:
Features GX-48 GX-520
Zones 16-48 16-520
Outputs (400mA) 8-24 8-24 8-260
Trigger Outputs on Flying Lead (100mA) 6 6
Power Supply Unit (PSU) 2.5A 2.5A
RS485 Databuses 1 4
Telecom onboard Yes Yes
RS232 Interface for online PC RS232 RS232
Printer Interface RS232 RS232
Ethernet option Yes Yes
Groups 8 32
Keypads 8 32
Multi-user Yes Yes
Door Control Modules (DCM's) with 2 x wiegand
interfaces
4 32
DCM Controlled doors 8 64
Access control groups (user templates) 50 100
Weekly Timer Schedules 19 67
Annual Holiday Schedules 16 32
Users 100 999
Links (Outputs) 64 256
Remote software update Yes Yes
Upload/Download Yes Yes
Remote service Yes Yes
Network downloader Yes Yes
Alarm monitoring Yes Yes
Graphics mimic Yes Yes
TouchCenter 1 4
Mimic panel Yes Yes
SMS (Short Message Service / Texting) Yes Yes
Table 1-1. GX-Series General Information
TERMINOLOGY GLOSSARY
Term Meaning Term Meaning
DCM Door Control Module RIO Remote Input Output
Module
Engineer Security System Installer Set / Setting Arm(ed) / Arming
ent
Enter key Unset / Unsetting Disarm(ed) / Disarming
esc
Escape key User Type User (Authority) Level
PA Personal/Panic Attack
Prox Reader Proximity card reader
Prox tag Proximity card
