GX-Series Control Panel Installation and Setup Guide
6-1
SECTION 6: SYSTEM OPERATION
TERMINOLOGY NOTES: ENGINEER = INSTALLER
SET / SETTING = ARM / ARMED / ARMING
UNSET / UNSETTING = DISARM / DISARMED / DISARMING
OMIT = BYPASS
Menu Options
General
The GX-Series provides various menu options for modifying the functional performance of the system. There
are two menu structures:
1. Full Menu — only accessed by authorized users including the master manager code and by the engineer
(installer).
2. Quick Menu — a selection of options from the full menu. The quick menu is the default menu access for
all user codes (type 2.3 and above), except master manager and engineer.
The Full Menu
The full menu has a hierarchy of 5 structures contained within it. Each structure is accessible by an
increased type of user code.
The Quick Menu
The quick menu offers type 2.3 and above users a selection of up to 10 options, numbered 0 – 9. The options
available from the quick menu can be modified to the user’s requirement via option 59 = QUICK MENU.
Quick Menu Full Menu
User
(Type 2.3)
User
(Type 2.4)
User
(Type 2.5)
Manager
(Type 3.6)
Engineer
(Type 3.7)
Engineer
(Type 3.7)
Engineer
(Type 3.7)
0 = Omit Zones
(Bypass Zones)
10 = Setting
(Arming
20 = Display 30 = Test 40 = Modify 50 = Engineer
1
60 =
Engineer 2
70 =
Engineer 3
1 = Forced set
(Forced bypass)
11 = Omit
Zones
(Bypass
Zones)
21 = Display
Zones
31 = Walk
Test
41 =
Time/Date
51 =
Parameters
61 =
Diagnostics
71 =
Program Key
2 = Chime 12 = Timed
Set (Arm)
22 = Display
Log
32 = Outputs 42 = Codes 52 = Program
Zones
62 = Full
Test
3 = Display
Zones
13 = Part
Set (Part
Arm)
23 = System 43 = Dlight
Saving
53 = Program
Outputs
63 = Options
4 = Display Log 14 = Forced
set (Forced
bypass)
24 = Print 44 = Trace 54 = Links 64 =
Assemble
Zone
5 = Print 15 = Chime 25 = Access
Doors
45 = Timer
Control
55 = Soak 65 = Timers
6 = Walk Test 16 = Instant
Set (Instant
Arm)
46 = Group
omit (Area
bypass)
56 =
Communication
66 = Pre-
Check
7 = Time/Date 17 = Silent
Part
47 = Remote
Access
57 = System
Print
67 = Remote
Reset
8 = Codes 18 = Home
Set (Home
Arm)
48 = Eng
Access
58 = Keypad 68 = Menu
Access
9 = Dlight
Saving
19 = All Set
(All Arm)
59 = Quick
Menu
69 = Access
Control
Table 6-1. Quick and Full Menu Options Reference
