1 = Codes
Prints user number and name, type and groups assigned;
NOTE: Only the manager can print out the user PINS; the Print Codes parameter (option 51.23) must
be enabled (default is disabled).
2 = Zones
Prints address, function, group (if group mode is enabled), status, descriptor (if assigned), status of
the chime, omit and part attributes, the RIO voltage and the zone resistance in Ohms;
3 = Log
Prints all events in the log, starting with the most recent and working backwards;
4 = All
Prints codes, zones and log details respectively.
The required option is selected by pressing the appropriate key 1-4. The printing begins immediately
and can be aborted by pressing esc.
Option 25 – Access Doors
This option displays information about the DCM readers with users connected to the system. There are 4
options:
1 = View All
This option displays the access log but with no filter. All events are displayed.
NOTE: If the Access mode has not been enabled (refer to option 69.1 = Mode) the message No Entries is
displayed on entering this option.
2 = User
This option shows all events for the selected user. Managers can see all the users. Individual users can
only see their own events.
3 = Reader
Accessing this option when the access mode is enabled (option 69.1) and there are DCM modules
connected to the system displays the address and descriptor details of the first DCM module on the
system. Press the A> and <B keys to view details of the other DCM modules on the system. If there are
no DCM modules attached to the system the message None Detected is displayed.
4 = Date
This option allows a specific date to be entered in the format DD/MM/YY. This forces the display to go to
a specific date.
Access Log
Access events are transmitted using Contact ID, SIA and Alarm Monitoring formats. Access events
transmitted are listed in Table 6-2. The GX-Series Access Log is capable of recording 1,000 events.
Event Description
SIA
Code
Contact
ID Code
Module
Number
User
ID
Access
Granted
Valid card
presented and
validated
DG 421 Yes Yes
Invalid Card Card
presented has
not been
programmed
onto system
DD 422 Yes No
Card Rejected Valid card
presented, but
rejected for
some reason
DK 422 Yes Yes
Table 6-2. Access Log Events
