Honeywell GX-Series User Manual

GX-Series Control Panel Installation and Setup Guide
B-1
Appendix B: SIA and Contact ID Event Codes
Ev SIA Event GX Log GX Log Event Ev Type GX Contact
Description Event Description Trigger ID
Event
A - Alarm Cause
AC Alarm Cause ALM CAUSE User report alarm cause USER ALWAYS TR None
A - AC Power
AR AC Restoral AC FAIL- AC Fail zone restored ZONE 13.ELEC.ST 301
CU-AC- Control Unit AC restored ZONE 13.ELEC.ST 301
AC FAIL- Module AC fail restored MOD. 13.ELEC.ST 301
STAND LOW- Standby Battery Low MOD 13.ELEC.ST 301
CU FUSE-
◊
Control Unit protection rest. MISC 9.TAMPER 300
13. ELEC.ST
AT AC Trouble AC FAIL+ AC Fail zone trouble ZONE 13.ELEC.ST 301
CU-AC+ Control Unit AC trouble ZONE 13.ELEC.ST 301
AC FAIL+ Module AC fail trouble MOD. 13.ELEC.ST 301
STAND LOW+ Standby Battery Low MOD 13.ELEC ST 301
CU FUSE+
◊
Control Unit protection trbl MISC 9. TAMPER 300
13.ELEC ST
FUSE AUX1
◊
Aux1 protection trouble MOD 9.TAMPER 300
13.ELEC ST
FUSE AUX2
◊
Aux2 protection trouble MOD 9.TAMPER 300
13.ELEC ST
FUSE BELL
◊
Bell protection trouble MOD 9.TAMPER 300
13.ELEC ST
B - Burglary
BA Burglary Alarm ENTRY Entry zone alarm ZONE NONE 150
EXIT+ Exit zone alarm ZONE 2.INTRUDE 134
INTRUDER+ Intruder zone alarm ZONE 2.INTRUDE 130
24 HOURS+ 24 hour zone alarm ZONE 3.24 HOURS 135
SECURITY+ Security zone alarm ZONE 4.SECURITY 135
DUAL+ Dual zone alarm ZONE 2.INTRUDE 130
FINAL Final zone alarm ZONE NONE 150
SEC FINAL+ Secure final zone alarm ZONE 4.SECURITY 134
PRT FINAL+ Part final zone alarm ZONE 2.INTRUDE 134
PRT ENTRY+ Part entry zone alarm ZONE 2.INTRUDE 134
BEAM PAIR+ Beam pair zone alarm ZONE 2.INTRUDE 130
VIDEO+ Video zone alarm ZONE 2.INTRUDE 130
VIDEO EXT+ Video exit zone alarm ZONE 2.INTRUDE 130
CUSTOM A+ Custom A zone alarm ZONE 5.CUS ZON 130
CUSTOM B+ Custom B zone alarm ZONE 5.CUS ZON 130
MASK+ Mask zone alarm ZONE 4.SECURITY 135
INT DELAY Intruder Delay alarm ZONE 2.INTRUDE 150
URGENT+ Urgent zone alarm ZONE 3.24 HOURS 130
VIBRATION+ Vibration zone alarm ZONE 2.INTRUDE 133
ATM-1+ ATM-1 zone alarm ZONE 3.24 HOURS 133
ATM-2+ ATM-2 zone alarm ZONE 3.24 HOURS 133
ATM-3+ ATM-3 zone alarm ZONE 3.24 HOURS 133
ATM-4+ ATM-4 zone alarm ZONE 3.24 HOURS 133
ALARM EXT+ Extend zone alarm ZONE 3.24 HOURS 130
T/O BURGL+ Entry timeout with zone ZONE 2.INTRUDE 134
BB Burg Bypass OMITTED Zone omitted ZONE 8.OMIT 573
FORCEOMT+ Force omit after rearm ZONE 8.OMIT 573
GRP OMIT+ Group omitted USER 8.OMIT 574
OMIT VIBS Omit Vibration zone EVENT 8.OMIT 572
OMIT-ATM1+ Omit ATM-1 zone EVENT 8.OMIT 572
OMIT-ATM2+ Omit ATM-2 zone EVENT 8.OMIT 572
OMIT-ATM3+ Omit ATM-3 zone EVENT 8.OMIT 572
OMIT-ATM4+ Omit ATM-4 zone EVENT 8.OMIT 572
BC Burg Cancel KSW CANCL Keyswitch Cancel ZONE 11.RESET 406
CANCEL Cancel by user USER 11.RESET 406
BF Intruder High INTR HIGH Intruder zone alarm ZONE 2. INTRUDE 130
◊
The PC board uses a PTC device instead of a fuse. The PTC serves as an automatically resetting fuse.
