GX-Series Control Panel Installation and Setup Guide
6-105
Option 57 – System Print
The System Print option allows the details of the system programming to be printed. There are 2 options
for the printer output:
1 = Printer Module
2 = Int RS232 1
From either option, the specific details of one or all of the menu options in the following table can be
selected:
Menu Option Menu No.
01 System Data 23
02 Codes 42
03 Parameters 51
04 Zones 52
05 Outputs 53
06 Links 54
07 Communication 56
08 ISDN 56.3
09 Groups 63
10 Keypads 58
11 Timers 65
12 Event Log 22
13 All (items 1-11)
Table 6-25. System Print Options
Selecting a Print Option
The required print option is selected by entering the option number 01 – 12 or by using the A> and <B keys
and then pressing ent. When printing option 11 = EVENT LOG, the system prompts for Groups to be
selected; the print shows only those events logged for the groups selected. The print can be aborted at any
time by pressing the esc key.
NOTE: A serial printer on line must be connected to communication line 1 of the GX-Series before the print
option is selected. If the printer is off-line or is not connected, the PRINTER off-line / ESC to abort
message is displayed. Press the ESC key and correct the problem.
Printing Timers
Printing 10 = Timers gives details of all the times that have been assigned in option 65 = TIMERS; this
includes the autoset time, the pre-warning period and lockout times.
