Honeywell GX-Series User Manual

GX-Series Control Panel Installation and Setup Guide
C-1
Appendix C: SIA Event Structure
Event
Type
SIA
LEVEL
ACC.
Block
DATA Block Format (N
block code)
Ascii Block Format
(A block code)
Explanation
3,4 #xxxxx Ntixx:xx/rixx/EVzzzz
Aeeeeeeeeesiiiiiiii
dddddddddddddddd
2 #xxxxxx Ntixx:xx/rixx/EVzzzz
1 #xxxxxx NEVzzzz
ZONE
0 #xxxx NEVzzzz
Detector alarmed, keyswitch etc
3,4 #xxxxxx Ntixx:xx/rixx/iduuu/pixxx/EV
Aeeeeeeeeesiiiiiiii
dddddd
2 #xxxxxx Ntixx:xx/rixx/iduuu/pixxx/EV
1 #xxxxxx NEVmmm
User
0 #xxxx NEVmmm
User Set/Unset, reset, duress, etc
3,4 #xxxxxx Ntixx:xx/rixx/pimmm/EV
Aeeeeeeeeesiiiiiiii
ddd
2 #xxxxxx Ntixx:xx/rixx/pimmm/EV
1 #xxxxxx NEVmmm
Module
0 #xxxx NEVmmm
1. With ri modifier: Set with A or B key
without code
2. 2. Without ri modifier: Keypad
added, Rio missing etc
3,4 #xxxxxx Ntixx:xx/rixx/EV Aeeeeeeeeesiiiiiiii
2 #xxxxxx Ntixx:xx/rixx/EV
1 #xxxxxx NEV
Event
0 #xxxx NEV000
1. With ri modifier: Automatic set,
timer activated
2. 2. Without ri modifier: Automatic
test, engineer mode
Key:
Data Block Ascii Block
ti Time modifier
ri Group modifier (not used if groups are disabled)
id User modifier
u User number
pi Peipheral modifier
m Peripheral number
EV Event Code Type (see SIA event list supplied)
z Zone number
x maximum digits for modifier field
e Log event (9 chars, see GX Log Event in table supplied)
s Event state ('+' : ON, '-' : OFF, ' ' : NOT USED)
i Site identifier (8 char description of site - can be blank)
d Descriptor (additional text to describe event),
1. Zone Event - 16 char zone descriptor
2. User Event - 6 char user name
3. Module Event - 3 char module name,
'RIO' (8 zone module), 'KEY' (keypad), 'MAX' (Proximity
Reader 'COM' (COM1 = Int Telecom, COM4 = Ethernet,
COM6 = Int RS232)
