Option 64 – Assemble Zone
The Assemble Zones option allows 2 zone functions to be customized to the user’s requirements; these are
the 1 Custom-A and 2 Custom-B zones. Once a custom zone function has been assembled, it is assigned to
zones using option 52 = PROGRAM ZONES.
Programming a Custom Zone
The flexibility of this menu option allows for an extensive range of possibilities. It is therefore important
that the engineer is fully aware of the system and has a clear picture of what is required of the new zone
function. The procedure for assembling a custom zone has 4 stages:
1. Outputs
2. Status
3. Setting (arming)
4. Log
1 = Outputs Output Type: Disabled Set
Unset
Set/Unset
A/B – select output type
# – toggle between Disabled, Set,
Unset & Set/Unset
esc – save programming
2 = Status 1 = Unset Disabled
Alarm
# – toggle between Disabled and
Alarm esc – save programming
2 = Entry/ Exit Disabled
Alarm
3 = Part Set Disabled
Alarm
4 = Full Set Disabled
Alarm
3 = Setting/
arming
1 = Begin Set Disabled
Enabled
# – toggle between Disabled and
Enabled
esc – save programming
2 = Begin
Entry
Disabled
Enabled
3 = Sets
System
Disabled
Enabled
4 = Log Disabled Entry
Exit 24 Hours
Alarms
# – toggle between Disabled,
Entry/Exit, 24 Hours & Alarms esc –
save programming
Table 6-29. Programming a custom Zone
1 = Outputs
Any of the available output types can be assigned to the custom zone. On selecting this attribute the
01=BELLS output type is displayed along with it status; the default status is disabled. The status
indicates the conditions under which the custom zone activates the output. To assign the output type
status press the # key, this toggles between each of the status settings:
1. Disabled the output is not activated by the custom zone,
2. Set the output is activated by the custom zone only when the system is set (armed),
3. Unset the output is activated by the custom zone only when the system is unset (disarmed).
4. Set/Unset the output is activated by the custom zone when the system is both set (armed) and
unset (disarmed).
Select the output types to be assigned by pressing the A> and <B keys or by entering the number of the
required output type and assign the required status. When all of the output types have been selected,
press the esc key to return the previous menu level. For a full list of output types refer to option 53 =
Program Outputs.
