Honeywell GX-Series User Manual

GX-Series Control Panel Installation and Setup Guide
6-88
No Trigger Event No Trigger Event
1 PA/Duress 11 Reset/Cancel
2 Intruder 12 Modules/Comms
3 24 Hours 13 Elec Status
4 Security 14 Menu Access
5 Custom Zones 15 Trouble
6 Fire 16 Log Zone
7 Set Fault 17 Max Tag
8 Omit 18 Zone Restoral
9 Tamper 19 RF Supervision
10 Setting 20 Fault
Table 6-24. Trigger Events
1 = Status
To modify the trigger, select the required trigger type using the A> and <B keys and press the ent key.
To program the status to On press 1, to set it to Off press 0. Press the ent key to save the programming
and return to the previous menu level.
Programming the SIA Format with Groups Enabled
If groups have been enabled on the system (refer to option 63 = OPTIONS), then the SIA format menu
alters slightly; an additional level is added.
1 = Trigger Events
On selecting the SIA level the keypad displays 1 = Trigger Events; press the ent key to display the
first trigger event; the keypad shows the trigger, the trigger status and the groups assigned.
1 = Status
To modify the trigger select the required trigger type using the A> and <B keys and press the ent
key. The 1 = Status option is then displayed. If the status requires to be modified, press the ent
key. To program the status to On press 1, to set it to Off press 0. Press the ent key to save the
programming and return to the previous menu level.
2 = Groups
If groups have been enabled on the system (refer to option 63 = OPTIONS), then groups can be
assigned to the events. This means that the events have to occur in assigned groups before they are
signaled. Press the A key, the keypad displays 2 = Group Settings and then press the ent key; the
status of the groups assigned to the trigger is displayed. If the group has Y below it, then this event
occurring in this group is signaled. If N is displayed, then the event is not signaled for that group. To
toggle the status of a group, enter the group number. When all the groups have been assigned press
the ent key to save the programming and return to the previous menu level.
Cross Group Confirmation
Confirmed outputs (and channels in DTMF format, option 56.1.1.1) will activate for alarms across groups
as long as both groups concerned have been assigned to that output or channel. In the point ID signaling
formats (SIA and Contact ID), confirmed signals will be transmitted across groups that share the same
account number. For example, in option 56.1.1.2 (SIA), it is possible to select a different account number for
each group on the system. Group 1 and group 2 can both be programmed with the same account number. If
there is a single activation in group 1 then a single intruder activation in group 2, within the confirmed time
window, a confirmed alarm signal will be transmitted for group 2.
Multi-group systems
The larger GX-Series panels have 32 groups; these are displayed on the keypad in blocks of eight groups,
sub-divided into A, B, C and D:
Use the A> or <B key to select the required group (A1–D8). When the end of a block is reached the next
block of eight groups is selected, press keys 1–8
to toggle the status of the relevant group in the current
bloc
k; press the ent key to accept the selection.
2 = Group Settings
NOTE: This option is only displayed if the groups have been enabled (refer to option 63 = OPTIONS).
