Honeywell GX-Series User Manual

GX-Series Control Panel Installation and Setup Guide
6-94
4 = Ethernet Module
4 = Ethernet
01= Module
Config
1 = IP Address
2 = Site Name
3 = Gateway IP
4 = Network Mask
02 = Alarm
Reporting
1 = Format
1 = SIA (0-4)
1 = Trigger
1 = Status
2 = Groups
2 = Groups Setting
1 = Account No.
2 = IP Address
3 = Port No.
2 = Microtech
2 = Primary IP
1 = IP Address
2 = Port No.
3 = Secondary IP
1 = IP Address
2 = Port No.
4 = Account No.
5 = Receiver
1 = Single
2 = Dual
6 = Alarm Mon.
1 = Trigger
1 = Status
2 = Groups
2 = Account No.
3 = IP Address
4 = Port No.
7 = Heartbeat
1 = Interval
8 = Protocol
0 = UDP
1 = TCP
03 = Remote
Access
1 = Access Period
1 = Off
2 = All unset
3 = Any Set
4 = Any Time
2 = Mode
1 = Direct access
2 = Mgr Authorize
1 = Call Back IP1
1 = IP Address
2 = Port No.
3 = Call Back IP3
1 = IP Address
2 = Port No.
4 = Call Back IP4
1 = IP Address
2 = Port No.
5 = Call Back IP5
1 = IP Address
2 = Port No.
2 = Call Back IP2
1 = IP Address
2 = Port No.
04 = Autotest 1 = Start Time
2 = Interval
05 = Engineer Test
06 = Fail to Comm
07 = Line Fail
1 = Network
0 = Off
1 = Available
2 = Signal Path
1 = Primary
2 = Secondary
3 = Alarm Mon.
4 = Any
5 = All
8 = SIA Control
1 = IP Address
9 = Encrypt
1 = Alarm Report
0 = Off
1 = On
2 = Remote Access
0 = Off
1 = On
3 = SIA Control
0 = Off
1 = On
4 = Alarm Mon.
0 = Off
1 = On
10 = Backup module
1 = Off
2 = NOT USED
3 = NOT USED
4 = NOT USED
5 = Int. Telecoms
6 = Int. RS232 1
GX-055-V1
Figure 6-9. Ethernet Module Programming Structure
NOTE: The
Encrypt option
is not used in
UL installations.
