GX-Series Control Panel Installation and Setup Guide
6-132
3 = Start Point
If the card structure is unknown then it can be decided where the card number starts from. This is a
numeric value that must be less than the maximum length of the card.
4 = User Field
This is where the facility code is specified. Two options can be selected:
1 = Field Position
This is the start bit for the facility code. It can be from 1 to the card number start point.
2 = Field Length
This is the length of the facility code. The maximum field length is from the field position to the start
of the card number.
