HP Apollo 4200 Gen9 - Page 141

Cabling 141
• Four-bay LFF hot-plug SATA rear drive cabling to the onboard SATA connector 1
Item Description
1
Rear LFF drive cage Mini-SAS x4 cable
2
Rear LFF drive cage power cable
• Four-bay LFF hot-plug SAS/SATA rear drive cabling to the H240 HBA installed in the PCIe
expansion slot 1 or 2
Item
Description
1
Rear LFF drive cage Mini-SAS x4 cable
2
Rear LFF drive cage power cable
