HP Apollo 4200 Gen9 User Manual

Cabling 146
• Two-bay SFF hot-plug SAS/SATA rear drive cabling to the P440 Smart Array Controller installed in
the PCIe riser slot 3 or 4
Item Description
1
Rear SFF drive cage Mini-SAS Y-cable
2
Rear SFF drive cage and two-slot PCI riser board power Y-cable
• Two-bay SFF hot-plug SAS/SATA rear drive cabling to the P440 Smart Array Controller installed in
the PCIe expansion slot 5, 6, or 7
Item Description
1
Rear SFF drive cage Mini-SAS Y-cable
2
Rear SFF drive cage and two-slot PCI riser board power Y-cable
