HP Apollo 4200 Gen9 User Manual

Cabling 145
• Two-bay SFF hot-plug SAS/SATA rear drive cabling to the H240 HBA installed in the PCIe
expansion slot 5 or 6
Item Description
1
Rear SFF drive cage Mini-SAS cable
2
Rear SFF drive cage and two-slot PCI riser board power Y-cable
• Two-bay SFF hot-plug SAS/SATA rear drive cabling to the P440 Smart Array Controller installed in
the PCIe expansion slot 1
Item Description
1
Rear SFF drive cage Mini-SAS Y-cable
2
Rear SFF drive cage and two-slot PCI riser board power Y-cable
