HP Apollo 4200 Gen9 - Page 148

Cabling 148
Item
Description
3
Rear SFF drive cage power cable
4
Rear SFF drive cage multiconnector signal cable
• Six-bay LFF hot-plug SAS/SATA rear drive cabling to the H240 HBA installed in the PCIe expansion
slot 1 or 2
Item Description
1
Rear SFF backplane sideband cable
2
Mini-SAS x4 cable
3
Rear SFF drive cage power cable
4
Mini-SAS x4 cable
• Six-bay LFF hot-plug SAS/SATA rear drive cabling to the H240 HBA installed in the PCIe expansion
slot 5, 6 or 7
