HP HPE Edgeline EL1000

To Next Page

To Previous Page

Front panel componentsFront panel components

ItemItem DescriptionDescription

1 iLO port

2 Network port 1

3 Network port 2

4 USB 3.0 ports (4)

5 Drives (2)

6 Blade

7 PXI/PXIe slot 3

8 PXI/PXIe slot 2

1G network connection

Front panel components 14
