Install the PXI/PXIe cardInstall the PXI/PXIe card
The system supports optional PXI cards.
NOTE:NOTE:
The PXI/PXIe card is not hot-pluggable. The system must be powered down to install this card.
ProcedureProcedure
1. Power down the system .
2. Remove the PXI/PXIe blank screws, and then remove the blank.
3. Align the PXI/PXIe card to the PXI/PXIe slot in the front panel.
4. Bend the tab and slide the PXI/PXIe card in until it clicks in place.
5. Install the PXI/PXIe card slot screws.
