HPE H240 Smart Host Bus Adapter port identificationHPE H240 Smart Host Bus Adapter port identification

ItemItem DescriptionDescription

1 Port 1

2 Port 2

Box 1 is drive 1 and box 2 is drive 2 for both ports.

HPE H240 Smart Host Bus Adapter port identification 21
